6-MAINTENANCE

Swingbearing

Greasetheswingbearingevery250h.

Lubricant:CASEAKCELA251HEPMULTI-PURPOSEGREASE

Swingbearing:onegreasetting

Usingagreasegun,injectgreaseofthespeciedtype

inthegreasepointsshowningure.

SMIL17MEX2657AA1

SMIL17MEX2649AA2

6-40
