CASE CONSTRUCTION CX26C - Machine orientation

1-GENERALINFORMATION
Machineorientation
Theterms"Right-hand","Left-hand","Front"and"Rear"
areusedinthismanualtoindicatethesidesastheyare
seenfromtheoperator'sseatwhenthetravelmotorsare
positionedattherearandtheoperatorisfacingthedirec-
tioninwhichthemachineadvances(forward).
A.Front
B.Rear
C.Right-handside
D.Left-handside
E.Travelmotor
F.Idlerwheel
SMIL16MEX0357BB1
