6-MAINTENANCE

Boomswingcylinder

Greasetheboomswingcylinderevery250h.

Lubricant:CASEAKCELAMOLYGREASE

Boomswingcylinder:onegreasetting

Usingagreasegun,injectgreaseofthespeciedtype

inthegreasepointsshowningure.

SMIL17MEX2657AA1

SMIL16MEX2520AA2

6-41
