3-CONTROLSANDINSTRUMENTS

(9)Auxiliaryfunction(AUXIN)

Ifyouwanttolistentomusicfromanexternalaudiode-

vice,openthecover(A)oftheAUXINfunction,connect

theexternalaudiodeviceusingtheAUXcable3,5mman

pushtheMODEbutton(B)toswitchtheAUXINmode.

IfanaudiolefromanexternalAudiodeviceisplaying,

themusicsoundsthroughthespeakersofthecab.

PushtheMODEbutton(B)toswitchotherradiomodes

andleavetheAUXINmode.

SMIL17MEX2806AA17

3-37
