CASE CONSTRUCTION CX26C - Page 173

6-MAINTENANCE
10.Useawrench[17mm]toremovetheboltandthen
removethebracket(1).
SMIL17MEX2719AB10
11.Useawrench[17mm]toremovethebolts(1)ofthe
hydraulicoilcooler(2).
12.Movethehydraulicoilcooler(2)anddetachitfromthe
radiator(3).
13.Loosentheclampandremovethehoses(4).
14.Removetheoilcooler(2).
SMIL17MEX2720AB11
15.Disconnectthenegative-terminalcable(-).Thendis-
connectthepositive-terminalcable(+).
16.Removethetwobolts(2)andtheplate(3).
17.Removethebattery(1).
18.Positionthenewbattery(1)onthemachine.
19.Installtheplate(3)toxthebatterybymeansofthe
twobolts(2).
20.Cleanthecablesandthebatteryterminals,andapply
grease.
21.Connectthepositive(+)andthenegative(-)cableto
thepositiveandthenegativeterminalofthebattery
respectively.
SMIL17MEX2383AB12
22.Closetheclampandinstallthehoses(4)totheoil
cooler(2).
23.Installtheoilcooler(2)totheradiator(3)andusea
wrench[17mm]totightenthebolts(1).
SMIL17MEX2721AB13
6-37
