6-MAINTENANCE
24.Installthebracket(1)anduseawrench[17mm]to
tightenthebolt.
SMIL17MEX2719AB14
25.Installthecoverbattery(2)anduseawrench[13mm]
totightenthebolt(1).
SMIL17MEX2718AB15
26.Installtheleft-handexternalshield.
27.Useawrench[13mm]totightentheboltsindicated
inthegure.
28.Installtheprotectivecaps.
SMIL16MEX1204AB16
29.Installtheleftsidebatterypanel(2).
30.Useawrench[13mm]totightenthethreebolts,and
theninserttheprotectivecaps(1).
31.Rellthehydraulicoilcircuitwiththerecommended
hydraulicoil.
SMIL17MEX2385AB17
6-38
