5-TRANSPORTOPERATIONS
Mechanicaltransportlock
12.Lockthebackhoeattachment:
A.Pressthebuttononthebackhoetransportlocklever
(1)andmoveitbackwardtoengagetheboomlock
B.Retracttheboomarmuntilthetransportlock(2)en-
gages.
NOTICE:Donotattempttousethebackhoeattachment
withtheboominthetransportposition,asthiscoulddam-
agethelockingsystem.
RAIL15TLB0052AA5
RAIL15TLB0048AA6
Hydraulictransportlock
12.Lockthebackhoeattachment:
A.Placetheswitch(1)intheONposition.Theindicator
lamp(2)(mechanicalbackhoecontrolmodels)orthe
indicatorlamp(3)(pilotbackhoemodels)turnson.
B.Retracttheboomarmuntilthetransportlockengages.
NOTICE:Donotattempttousethebackhoeattachment
withtheboominthetransportposition,asthiscoulddam-
agethelockingsystem.
LEEN11T0146AA7
MOLI12LBB0249AB8
