CHAPTER 6 – LUBRICATION / FILTERS / FLUIDS
6-14
GREASE FITTINGS
Each 250 hours services
Front Wheel Knuckle
There are 2 lube points. Lubricate with 4 to 6 shots on
each side.
FRONT WHEEL KNUCKLE
Steering Arm Pivot
There are 4 lube points. Lubricate with 4 to 6 shots on
each side.
STEERING ARM PIVOT
Wheel Lean Link
There are 2 lube points. Lubricate with 4 to 6 shots on
each side.
WHEEL LEAN LINK
Front Wheel Lean Cylinder
There are 2 lube points. Lubricate with 4 to 6 shots on
each side.
FRONT WHEEL LEAN CYLINDER
