CHAPTER 3 – INSTRUMENTS AND CONTROLS
3-4
1
2
5
6
3
4
FLOODLIGHTS, HEADLIGHTS LOW AND HIGH BEAM, 1.
DIRECTIONAL LIGHTS AND HORN LEVER
STEERING WHEEL2.
STEERING WHEEL TILTING LEVER 3.
FRONT CONSOLE (ABOVE STEERING WHEEL)4.
FRONT CONSOLE (BELOW STEERING WHEEL)5.
SWITCHBOARD6.
GROUP 2
Steering wheel, console, pedals and fuse box
10
8
9
7
11
12
INCHING PEDAL 7.
(ONLY FOR 845B / 865B / 885B MODELS
WITH FUNK TRANSMISSION
CONSOLE TILT PEDAL8.
BRAKE PEDAL9.
ACCELERATOR / DECELERATOR PEDAL10.
FRONT CONSOLE FUSE BOX AND RELAYS11.
IGNITION SWITCH12.
