CHAPTER 3 – INSTRUMENTS AND CONTROLS
3-12
K. HYDRAULIC FLUID TEMPERATURE GAUGE
The gauge shows the hydraulic oil temperature. The operating normal temperature is within the green area.
When the hydraulic oil temperature rises, the gauge goes to the yellow area, the warning alarm sounds for
3 seconds, and the master warning indicator changes to yellow. When the temperature continues rising, the
gauge goes to the red area and the warning alarm sounds continuously. The master stop indicator becomes
red. The machine MUST NOT be operated when the temperature is in the red area.
HYDRAULIC OIL TEMPERATURE GAUGE
Gauge Indication Condition Master Indicator Gauge Status Alarm Status
20°C and below
(68°F and below)
Hydraulic oil temperature
is very low.
Caution (Yellow) Continuous 3 Seconds
20°C to 105°C
(68°F to 221°F)
Hydraulic oil temperature
is normal.
105°C to 110°C
(221°F to 230°F)
Hydraulic oil temperature
is high.
Caution (Yellow) Continuous
110°C and above
(230°F and above)
Hydraulic oil temperature
very high.
Stop (Red) Continuous
Intermittent
(0,5 sec. ON and
0,2 sec. OFF)
NOTE: Do not operate the machine, if the indicator is red and the alarm sounds continuously. Stop the machine and
correct the defect
.
