Cedar Summit F25650 - Page 24

I: Turn the Table Assembly right side up.
J: Place the Sand and Water Insert into the opening of the assembly then tighten all the bolts. (g. 1.9)
K: Secure the Sand and Water Insert to the assembly using 6 (S13) #6 x 5/8” Pan Screws as shown in g. 1.10
and 1.11.
L: Place the Seat over the Sand and Water Insert.
Other Parts
1 x Seat
1 x Sand and Water Insert
6 x #6 x 5/8” Pan Screw
Hardware
Step 1: Sand and Water Table Assembly
Part 4
Seat
Fig. 1.10
Fig. 1.9
Fig. 1.11
Fig. 1.12
Sand and
Water Insert
Seat
S13
S13
S13
