Cedar Summit F25650 - Page 31

Step 4: Panel Preparation
Part 3
Hardware
E: From the back of (042) Chalkwall Panel place the Spin Chalk Sign in the opening so it sits tight to the panel.
(g. 4.7 and 4.8)
F: Attach Spin Chalk Sign to (042) Chalkwall Panel with 6 (S5) #8 x 1/2” Pan Screws. (g. 4.8)
6 x #8 x 1/2” Pan Screw
S5
Other Parts
1 x Spin Chalk Sign
1 x Chalkwall Panel FSC 1-1/4 x 16-3/4 x 56”
Wood Parts
042
042
Fig. 4.8
Front
Fig. 4.7
Back
S5
042
Spin Chalk Sign
31 support@cedarsummitplay.com
