Step 4: Panel Preparation
Part 4
Hardware
G: Place (044) SW Wall at the top of the front of (043) SW
Side Panel and attach with 4 (G21) 5/16 x 3-3/4” Hex Bolts
(with lock washer, at washer and t-nut). (g. 4.9 and 4.10)
1 x SW Side Panel FSC 1-1/4 x 36 x 87-1/4”
1 x SW Wall FSC 4 x 4 x 38-1/2”
Wood Parts
043
044
5/16” Flat
Washer
5/16” t-nut
5/16” Lock
Washer
Fig. 4.10
043
Fig. 4.9
G21
Front Side
044
043
4 x 5/16 x 3-3/4” Hex Bolt
(5/16”lockwasher,5/16”atwasher&5/16”t-nut)
G21
044
