CET Electric Technology
74
0=Stop-when-Full
1=First-In-First-Out
Please refer to Appendices
A and B for a complete list
of the Data Recorder
Parameters and the default
configuration for each DR,
respectively.
Table 5-42 DR Setup Parameter Data Structure
Notes:
1) Changing any of these Data Recorder setup registers will reset the Data Recorder.
2) Recording Offset can be used to delay the recording by a fixed amount of time from the
Recording Interval. For example, if the Recording Interval is set to 3600 (hourly) and the
Recording Offset is set to 300 (5 minutes), the recording will take place at 5 minutes after the
hour every hour, i.e. 00:05, 01:05, 02:05…etc. The value of the Recording Offset parameter
should be less than the Recording Interval parameter.
5.12 TOU Setup
5.12.1 Basic
0=T1, 1=T2, 2=T3, 3=T4
4=T5, 5=T6, 6=T7, 7=T8
0 to 11
(Season #1 to #12)
0 to 11
(Period #1 to #12)
Current Daily Profile No.
0 to 19
(Daily Profile #1 to #20)
0=Weekday1
1=Weekday2
2=Weekday3
3= Alternate Day
Write 0xFF00 to manually
switch the TOU schedules
0=Weekday1*
1=Weekday2
2=Weekday3
Table 5-43 TOU Basic Setup
Notes:
1) If DI1 is not programmed as a Tariff Switch, the TOU will function based on the TOU Schedule. If at
least one DI (DI1) is programmed as a Tariff Switch, the TOU Schedule will no longer be used and
the Tariff switching will be based on the status of the DIs.
2) The following table illustrates the data structure for the TOU Switch Time. For example, 0x1003140C
indicates a switch time of 12:00pm on March 20
th
, 2016. Writing 0xFFFFFFFF to this register disables
the switching between TOU Schedule.
Table 5-44 TOU Switch Time Format
