Appendix C BACNet MSTP Implementation
1) Basic Information
The PMC-53A with the Firmware V1.00.03 or later supports the BACnet MS/TP protocol and can
easily be connected to a BACnet MS/TP network using an off-the shelf BACnet router. The PMC-
53A provides four types of BACnet objects. Standard Protocol Implementation Conformance
Statement (PICS) as illustrated in table below describes the required characteristics of the BACnet
implementation.
Item
Description
Date
March 20, 2017
Vendor Name
CET
Model Name
PMC-53A
Applications Software Version
1.00.03
Firmware Revision
1.0
Protocol Version
1
Protocol Revision
7
Description
Intelligent Multifunction Meter
Standardized Device
BACnet Smart Actuator (B-SA)
Interoperability Building
Blocks supported
DS-RP-B, DS-RPM-B, DS-WP-B, DM-DOB-B, DM-TS-B, DM-DDB-B
Segmentation Capability
Not Supported
Data Link Layer Options
MS/TP Master, Baud rate(s): 1200, 2400, 4800, 9600, 19200,
38400
Device Address Binding
None
Networking Options
None
Character Sets Support
ANSI X3.4
2) Device Objects
 Optional Properties Supported: Description, Local_Time, Local_Date, Location
 Writable Properties: Object_Identifier, Number_Of_APDU_Reries, APDU_Timeout,
System_Status, Object_Name, Location, Description, Max_Master, Max_Info_Frame,
Local_Time, Local_Date
 Property Range Restrictions: Object_Identifier - valid range is between 0 and 4194302;
Object_Name - limited to 32 characters; Location - limited to 64 characters; Description -
limited to 64 characters; Max_Master – valid range is between 1 and 127.
The following table illustrates the Device Objects on the PMC-53A:
Property*
Description
Range/Values
Default
R/W
Object_Identifier
0 to 4194302
26001
R/W
Object_Name
Up to 32 characters
Simple Server
R/W
System_Status
Operational (0)
R
Object_Type
Device (8)
R
Vendor_Name
CET
R/W
Vendor_Identifier
593
R
Model_Name
PMC-53A
R
Firmware_Revision
1
R
Application_Software_Version
1.00.03
R/W
Location
Up to 64 characters
LOCAL
R/W
Description
Up to 64 characters
Intelligent
Multifunction Meter
R
Protocol_Version
1
R
Protocol_Revision
7
R
Protocol_Service_Supported
1
Please see notes below
R
Protocol_Object_Types_Supported
2
Please see notes below
R
Object_List
Please refer to sections
3) to 6)
R
Max_APDU_Length_Accepted
480
R
Segmentation
NO_SEGMENTATION
