CET PMC-53A User Manual

CET Electric Technology
99
Appendix F Technical Specifications
Voltage Inputs (V1, V2, V3, VN)
Standard Un
Range
Overload
Burden
Measurement Category
400VLN/690VLL
10V to 1.2Un
1.2xUn continuous, 2xUn for 1s
<0.02VA per phase
CAT III up to 600VLL
Frequency
45-65Hz
Current Inputs (I11, I12, I21, I22, I31, I32)
Standard In=5A/1A Auto-scale
Optional In=1A
Range
Starting Current
Overload
Measurement Category
Burden
Class 0.5S for 5A and Class 1 for 1A
Class 0.5S
0.1% to 200% In
0.1% In
2xIn continuous, 20xIn for 1s
CAT III up to 600VLL
<0.15VA per phase
Optional I4 Input (I41, I42)
In
Range
Starting Current
5A (5A/1A Auto-Scale)
0.1% to 120% In
0.1% In
Power Supply (L+, N-, GND)
Standard
Optional
Optional
Burden
Overvoltage Category
95-250VAC/DC, ±10%, 47-440Hz
20-60VDC
95-480VAC/DC, ±10%, 47-440Hz
<2W
CAT III up to 300VLN
Digital Inputs (DI1, DI2, DI3, DI4, DIC)
Type
Sampling
Hysteresis
Dry contact, 24VDC internally wetted
1000Hz
1ms minimum
Digital Outputs (DO11, DO12, DO21, DO22)
Type
Loading
Form A Mechanical Relay
5A @ 250VAC or 30VDC
Pulse Outputs (kWh, kvarh)
Type
Isolation
Max. Load Voltage
Max. Forward Current
Form A Solid State Relay
Optical
80V
50mA
Installation Torque
Current Inputs
1.3 N.m
Power Supply, Voltage Inputs,
RS485 and I/O
0.5 N.m
Environmental Conditions
Operating Temp.
Storage Temp.
Humidity
Atmospheric Pressure
-25°C to 70°C
-40°C to 85°C
5% to 95% non-condensing
70 kPa to 106 kPa
Mechanical Characteristics
Panel Cutout
Unit Dimensions
IP Rating
92x92 mm (3.62”x3.62”)
96x96x88 mm
65
