CET Electric Technology
73
P DMD (kW Total Present Demand)
Q DMD (kvar Total Present Demand)
S (kVA Total Present Demand)
P DMD Pred (kW Total Predicted Demand)
Q DMD Pred (kvar Total Predicted Demand)
S DMD Pred (kVA Total Predicted Demand)
U Unbal (Voltage Unbalance)
I Unbal (Current Unbalance)
Reversal (Phase Reversal)
3
* Valid only if the device is equipped with the appropriate option
~ Available in Firmware V1.00.06
Table 5-39 Setpoint Parameters
2) For Over Setpoint, the setpoint parameter must exceed the Over Limit to become active and go
below the Under Limit to become inactive.
For Under Setpoint, the setpoint parameter must go below the Under Limit to become active and
exceed the Over Limit to become inactive.
3) The PMC-53A provides the following Setpoint Triggers:
Table 5-40 Setpoint Triggers
4) Only when DOx Mode is set to Remote Control/Setpoint, setting Setpoint Triggers to DOx Closed
is valid. In addition,
Only when the PMC-53A’s Basic Function option is “3” (4xDI+3xRelay Output) or “A”
(4xDI+2xSS Pulse Output) would setting the Setpoint Trigger to DO1 Closed or DO2 Closed
have meaning.
Only when the Expansion Module B is equipped with the “2xDI + 2xDO (Relay Output)” or
“2xDI + 2xSS Pulse Output” options would setting the Setpoint Trigger to DO3 Closed or DO4
Closed have meaning.
5.11.5 Data Recorder Setup
See Table 5-42 DR
Setup Parameter Data
Structure
* Please refer to Appendix B for the default configuration for the Data Recorders.
Table 5-41 Data Recorder Setup
0=Disabled
1=Triggered by Timer
To Next Page
