CET PMC-53A - 5.5.4 Peak Demand Log of Last Month (Before Last Reset); 5.6 Max.;Min. Log; 5.6.1 Max. Log of This Month (Since Last Reset)

CET Electric Technology
58
3630~3635
RO
kVA Total
VA
3636~3641
RO
kW Total of T1
W
3642~3647
RO
kvar Total of T1
var
3648~3653
RO
kVA Total of T1
VA
3654~3659
RO
kW Total of T2
W
3660~3665
RO
kvar Total of T2
var
3666~3671
RO
kVA Total of T2
VA
3672~3677
RO
kW Total of T3
W
3678~3683
RO
kvar Total of T3
var
3684~3689
RO
kVA Total of T3
VA
3690~3695
RO
kW Total of T4
W
3696~3701
RO
kvar Total of T4
var
3702~3707
RO
kVA Total of T4
VA
3708~3713
RO
kW Total of T5
W
3714~3719
RO
kvar Total of T5
var
3720~3725
RO
kVA Total of T5
VA
3726~3731
RO
kW Total of T6
W
3732~3737
RO
kvar Total of T6
var
3738~3743
RO
kVA Total of T6
VA
3744~3749
RO
kW Total of T7
W
3750~3755
RO
kvar Total of T7
var
3756~3761
RO
kVA Total of T7
VA
3762~3767
RO
kW Total of T8
W
3768~3773
RO
kvar Total of T8
var
3774~3779
RO
kVA Total of T8
VA
Table 5-16 Peak Demand Log of Last Month (Before Last Reset)
5.5.5 Demand Data Structure
Offset
Description
+0
High
Year - 2000
Low
Month
+1
High
Day
Low
Hour
+2
High
Minute
Low
Second
+3
-
Millisecond
+4~+5
-
Peak Demand Value
Table 5-17 Demand Data Structure
5.6 Max./Min. Log
5.6.1 Max. Log of This Month (Since Last Reset)
Register
Property
Description
Format
Scale
Unit
4000~4005
RO
Uan
See 5.6.5
Max./Min. Log
Structure
x1
V
4006~4011
RO
Ubn
4012~4017
RO
Ucn
4018~4023
RO
Uln Average
4024~4029
RO
Uab
4030~4035
RO
Ubc
4036~4041
RO
Uca
4042~4047
RO
Ull Average
4048~4053
RO
Ia
x1
A
4054~4059
RO
Ib
4060~4065
RO
Ic
4066~4071
RO
I Average
4072~4077
RO
kWa
x1
W
4078~4083
RO
kWb
4084~4089
RO
kWc
4090~4095
RO
kW Total
4096~4101
RO
kvara
x1
var
4102~4107
RO
kvarb
4108~4113
RO
kvarc
4114~4119
RO
kvar Total
