CET PMC-53A User Manual

CET Electric Technology
76
5.12.3 Daily Profile
The PMC-53A has two sets of Daily Profile setup parameters, one for each TOU.
Register
Property
Description
Format
7200~7223
RW
Daily Profile #1
See Table 5-48
Daily Profile Data
Structure
7224~7247
RW
Daily Profile #2
7248~7271
RW
Daily Profile #3
7272~7295
RW
Daily Profile #4
7296~7319
RW
Daily Profile #5
7320~7343
RW
Daily Profile #6
7344~7367
RW
Daily Profile #7
7368~7391
RW
Daily Profile #8
7392~7415
RW
Daily Profile #9
7416~7439
RW
Daily Profile #10
7440~7463
RW
Daily Profile #11
7464~7487
RW
Daily Profile #12
7488~7511
RW
Daily Profile #13
7512~7535
RW
Daily Profile #14
7536~7559
RW
Daily Profile #15
7560~7583
RW
Daily Profile #16
7584~7607
RW
Daily Profile #17
7608~7631
RW
Daily Profile #18
7632~7655
RW
Daily Profile #19
7656~7679
RW
Daily Profile #20
Table 5-46 TOU #1’s Daily Profile Setup
Register
Property
Description
Format
8200~8223
RW
Daily Profile #1
See Table 5-48
Daily Profile Data
Structure
8224~8247
RW
Daily Profile #2
8248~8271
RW
Daily Profile #3
8272~8295
RW
Daily Profile #4
8296~8319
RW
Daily Profile #5
8320~8343
RW
Daily Profile #6
8344~8367
RW
Daily Profile #7
8368~8391
RW
Daily Profile #8
8392~8415
RW
Daily Profile #9
8416~8439
RW
Daily Profile #10
8440~8463
RW
Daily Profile #11
8464~8487
RW
Daily Profile #12
8488~8511
RW
Daily Profile #13
8512~8535
RW
Daily Profile #14
8536~8559
RW
Daily Profile #15
8560~8583
RW
Daily Profile #16
8584~8607
RW
Daily Profile #17
8608~8631
RW
Daily Profile #18
8632~8655
RW
Daily Profile #19
8656~8679
RW
Daily Profile #20
Table 5-47 TOU #2’s Daily Profile Setup
Offset
Property
Description
Format
Note
+0
RW
Period #1 Start Time
UINT16
0x0000
+1
RW
Period #1 Tariff
UINT16
0=T1, …, 7=T8
+2
RW
Period #2
Start Time
High-order Byte: Hour
UINT16
0 ≤ Hour < 24
Low-order Byte: Min
Min = 0, 15, 30, 45
+3
RW
Period #2 Tariff
UINT16
0=T1, …, 7=T8
+4
RW
Period #3 Start Time
UINT16
See Period #2 Start Time
+5
RW
Period #3 Tariff
UINT16
0=T1, …, 7=T8
+6
RW
Period #4 Start Time
UINT16
See Period #2 Start Time
+7
RW
Period #4 Tariff
UINT16
0=T1, …, 7=T8
+8
RW
Period #5 Start Time
UINT16
See Period #2 Start Time
+9
RW
Period #5 Tariff
UINT16
0=T1, …, 7=T8
+10
RW
Period #6 Start Time
UINT16
See Period #2 Start Time
+11
RW
Period #6 Tariff
UINT16
0=T1, …, 7=T8
+12
RW
Period #7 Start Time
UINT16
See Period #2 Start Time
