CET PMC-53A User Manual

CET Electric Technology
72
8
kW Total
x1
kW
18
Ucn
V
9
kvar Total
kvar
19
Uln Average
V
Table 5-36 Analog Output Parameters
5.11.3 Communication Setup Parameters
Register
Property
Description
Format
Range, Default*
6400
RW
Port1 Protocol
UINT16
0=Modbus RTU*
1=BACnet/MSTP
#
2=N2
#
, 3=DNP~
6401
RW
Port1 Unit ID
UINT16
Modbus RTU/N2: 1 to 247
BACnet/MSTP: 1 to 127
DNP: 0 to 65519
Default=100
6402
RW
Port1 Baud Rate
1
UINT16
0=1200, 1=2400, 2=4800,
3=9600*, 4=19200, 5=38400
6403
RW
Port1 Comm. Config.
UINT16
0=8N2, 1=8O1,2=8E1*
3=8N1, 4=8O2, 5=8E2
6404
RW
Port2 Protocol
UINT16
0=Modbus RTU*
6405
RW
Port2 Unit ID
UINT16
1 to 247, 101*
6406
RW
Port2 Baud Rate
1
UINT16
0=1200, 1=2400, 2=4800,
3=9600*, 4=19200, 5=38400
6407
RW
Port2 Comm. Config.
UINT16
0=8N2, 1=8O1,2=8E1*
3=8N1, 4=8O2, 5=8E2
#
Available in Firmware V1.00.03 or later. Please refer to Appendices C and D for the detailed information of BACnet MSTP and
N2 protocol.
~Available in Firmware V1.00.06 or later. Please refer to Appendix E for the detailed information of DNP.
Table 5-37 Communication Setup
Notes:
1) If the Baud Rate is set to an invalid value, it will default to 9600bps automatically.
5.11.4 Setpoints Setup
Register
Property
Description
Format
Range, Default*
6500
RW
Setpoint #1
Setpoint Type
UINT16
0=Disabled*
1=Over Setpoint
2=Under Setpoint
6501
RW
Parameters
1
UINT16
0 to 32
6502
RW
Over Limit
2
Float
0*
6504
RW
Under Limit
2
Float
0*
6506
RW
Active Delay
UINT16
0 to 9999 s, 10*
6507
RW
Inactive Delay
UINT16
0 to 9999 s, 10*
6508
RW
Trigger Action 1
3
UINT16
0 to 4
6509
RW
Trigger Action 2
3
UINT16
…
…
…
6580
RW
Setpoint #9
Setpoint Type
UINT32
0=Disabled*
1=Over Setpoint
2=Under Setpoint
6581
RW
Parameter
1
UINT16
0* to 32
6582
RW
Over Limit
Float
0*
6584
RW
Under Limit
Float
0*
6586
RW
Active Delay
UINT16
0 to 9999 s, 10*
6587
RW
Inactive Delay
UINT16
0 to 9999 s, 10*
6588
RW
Trigger Action 1
2
UINT16
0 to 4
6589
RW
Trigger Action 2
2
UINT16
Table 5-38 Setpoint Setup Parameters
Notes:
1) The PMC-53A provides the following setpoint parameters:
Key
Setpoint Parameter
Scale
Unit
0
None
-
-
1
Uln (Any Phase Voltage)
x1
V
2
Ull (Any Line Voltage)
3
I (Any Phase Current)
A
4
In (Calculated)
5
Frequency
Hz
