CET PMC-53A User Manual

CET Electric Technology
77
+13
RW
Period #7 Tariff
UINT16
0=T1, …, 7=T8
+14
RW
Period #8 Start Time
UINT16
See Period #2 Start Time
+15
RW
Period #8 Tariff
UINT16
0=T1, …, 7=T8
+16
RW
Period #9 Start Time
UINT16
See Period #2 Start Time
+17
RW
Period #9 Tariff
UINT16
0=T1, …, 7=T8
+18
RW
Period #10 Start Time
UINT16
See Period #2 Start Time
+19
RW
Period #10 Tariff
UINT16
0=T1, …, 7=T8
+20
RW
Period #11 Start Time
UINT16
See Period #2 Start Time
+21
RW
Period #11 Tariff
UINT16
0=T1, …, 7=T8
+22
RW
Period #12 Start Time
UINT16
See Period #2 Start Time
+23
RW
Period #12 Tariff
UINT16
0=T1, …, 7=T8
Table 5-48 Daily Profile Data Structure
Notes:
1) Daily Profile #1’s Period #1 Start Time is always 00:00 and cannot be modified.
2) Setting a Period’s Start Time as 0xFFFF terminates the Daily Profile’s settings. All subsequent Daily
Profiles’ setup parameters will be ignored, and the previous Period’s duration is from its Start Time
to the end of the day.
3) The minimum interval of a period is 15 minutes.
4) The Start Time of a particular Period must be later than the previous Period’s .
5.12.4 Alternate Days
Each Alternate Day is assigned a Daily Profile and has a higher priority than Season. If a particular date
is set as an Alternate Day, its assigned Daily Profile will override the “normal” Daily Profile for this day
according the TOU settings.
The PMC-53A has two sets of Alternate Days setup parameters, one for each TOU. The Base Addresses
for the two sets are 7700 and 8700, respectively, where the Register Address = Base Address + Offset.
For example, the register address for TOU #2’s Alternative Day #2’s Date is 8700+3 = 8703.
Offset
Property
Description
Format
Range/Default*
0
RW
Alternate Day #1 Date¹
UINT32
Table 5-50
2
RW
Alternate Day #1 Daily Profile
UINT16
0* to 19
3
RW
Alternate Day #2 Date¹
UINT32
Table 5-50
5
RW
Alternate Day #2 Daily Profile
UINT16
0* to 19
6
RW
Alternate Day #3 Date¹
UINT32
Table 5-50
8
RW
Alternate Day #3 Daily Profile
UINT16
0* to 19
9
RW
Alternate Day #4 Date¹
UINT32
Table 5-50
11
RW
Alternate Day #4 Daily Profile
UINT16
0* to 19
12
RW
Alternate Day #5 Date¹
UINT32
Table 5-50
14
RW
Alternate Day #5 Daily Profile
UINT16
0* to 19
15
RW
Alternate Day #6 Date¹
UINT32
Table 5-50
17
RW
Alternate Day #6 Daily Profile
UINT16
0* to 19
18
RW
Alternate Day #7 Date¹
UINT32
Table 5-50
19
RW
Alternate Day #7 Daily Profile
UINT16
0* to 19
21
RW
Alternate Day #8 Date¹
UINT32
Table 5-50
22
RW
Alternate Day #8 Daily Profile
UINT16
0* to 19
24
RW
Alternate Day #9 Date¹
UINT32
Table 5-50
25
RW
Alternate Day #9 Daily Profile
UINT16
0* to 19
27
RW
Alternate Day #10 Date¹
UINT32
Table 5-50
29
RW
Alternate Day #10 Daily Profile
UINT16
0* to 19
…
…
Table 5-50
…
…
0* to 19
240
RW
Alternate Day #81 Date¹
UINT32
Table 5-50
162
RW
Alternate Day #81 Daily Profile
UINT16
0* to 19
243
RW
Alternate Day #82 Date¹
UINT32
Table 5-50
245
RW
Alternate Day #82 Daily Profile
UINT16
0* to 19
246
RW
Alternate Day #83 Date¹
UINT32
Table 5-50
248
RW
Alternate Day #83 Daily Profile
UINT16
0* to 19
249
RW
Alternate Day #84 Date¹
UINT32
Table 5-50
251
RW
Alternate Day #84 Daily Profile
UINT16
0* to 19
