CET PMC-53A User Manual

CET Electric Technology
59
4120~4125
RO
kVAa
x1
VA
4126~4131
RO
kVAb
4132~4137
RO
kVAc
4138~4143
RO
kVA Total
4144~4149
RO
PFa
x1
-
4150~4155
RO
PFb
4156~4161
RO
PFc
4162~4167
RO
PF Total
4168~4173
RO
Frequency
x1
Hz
4174~4179
RO
In (Calculated)
x1
A
4180~4185
RO
Uan/Uab THD
x1
-
4186~4191
RO
Ubn/Ubc THD
4192~4197
RO
Ucn/Uca THD
4198~4203
RO
Ia THD
4204~4209
RO
Ib THD
4210~4215
RO
Ic THD
4216~4221
RO
Ia K-factor
4222~4227
RO
Ib K-factor
4228~4233
RO
Ic K-factor
4234~4239
RO
Ia Crest-factor
4240~4245
RO
Ib Crest-factor
4246~4251
RO
Ic Crest-factor
4252~4257
RO
Voltage Unbalance
4258~4263
RO
Current Unbalance
4264~4269
RO
I4
x1
A
4270~4275
RO
Ir* (Residual Current)
#
Available in Firmware V1.00.06 or later
Table 5-18 Max. Log of This Month (Since Last Reset)
5.6.2 Min. Log of This Month (Since Last Reset)
Register
Property
Description
Format
Scale
Unit
4300~4305
RO
Uan
See 5.6.5
Max./Min. Log
Structure
x1
V
4306~4311
RO
Ubn
4312~4317
RO
Ucn
4318~4323
RO
Uln Average
4324~4329
RO
Uab
4330~4335
RO
Ubc
4336~4341
RO
Uca
4342~4347
RO
Ull Average
4348~4353
RO
Ia
x1
A
4354~4359
RO
Ib
4360~4365
RO
Ic
4366~4371
RO
I Average
4372~4377
RO
kWa
x1
W
4378~4383
RO
kWb
4384~4389
RO
kWc
4390~4395
RO
kW Total
4396~4401
RO
kvara
x1
var
4402~4407
RO
kvarb
4408~4413
RO
kvarc
4414~4419
RO
kvar Total
4420~4425
RO
kVAa
x1
VA
4426~4431
RO
kVAb
4432~4437
RO
kVAc
4438~4443
RO
kVA Total
4444~4449
RO
PFa
x1
-
4450~4455
RO
PFb
4456~4461
RO
PFc
4462~4467
RO
PF Total
4468~4473
RO
Frequency
x1
Hz
4474~4479
RO
In (Calculated)
x1
A
4480~4485
RO
Uan/Uab THD
x1
-
4486~4491
RO
Ubn/Ubc THD
4492~4497
RO
Ucn/Uca THD
4498~4503
RO
Ia THD
