CET PMC-53A User Manual

CET Electric Technology
91
Appendix E DNP Profile
This section contains the DNP Device Profile Information according to the standard format defined in
the DNP 3.0 Subset Definitions Document and should provide a complete application configuration
guide.
DNP V3.0
Vendor Name: CET
Device Name: PMC-53A
Highest DNP Level Supported:
For Requests: Level 1
For Responses: Level 1
Device Function:
 Master
 Slave
Notable objects, functions, and/or qualifiers supported in addition to the Highest DNP levels Supported (the complete list is
described in the attached table):
Maximum Data Link Frame Size (octets):
Transmitted: 292
Received: 292
Maximum Application Fragment Size (octets):
Transmitted: 1024
Received: 300
Maximum Data Link Re-tries:
 None
 Fixed
 Configurable
Maximum Application Layer Re-tries:
 None
 Configurable
Requires Data Link Layer Confirmation:
 Never
 Always
 Sometimes
 Configurable
Requires Application Layer Confirmation:
 Never
 Always
 When reporting Event Data (Slave devices only)
 When sending multi-fragment responses (Slave devices only)
 Sometimes
 Configurable
Timeouts while waiting for:
Data Link Confirm:  None  Fixed at ___  Variable  Configurable
Complete Appl. Fragment:  None  Fixed at ___  Variable  Configurable
Application Confirm:  None  Fixed at ___  Variable  Configurable
Complete Appl. Response:  None  Fixed at ___  Variable  Configurable
Others: Transmission Delay, configurable
Select/Operate Arm Timeout, fixed at 15 seconds
Sends/Executes Control Operations:
WRITE Binary Outputs  Never  Always  Sometimes  Configurable
SELECT/OPERATE  Never  Always  Sometimes  Configurable
DIRECT OPERATE  Never  Always  Sometimes  Configurable
DIRECT OPERATE - NO ACK  Never  Always  Sometimes  Configurable
Count > 1  Never  Always  Sometimes  Configurable
Pulse On:  Never  Always  Sometimes  Configurable
Pulse Off:  Never  Always  Sometimes  Configurable
Latch On  Never  Always  Sometimes  Configurable
Latch Off  Never  Always  Sometimes  Configurable
Queue:  Never  Always  Sometimes  Configurable
Clear Queue:  Never  Always  Sometimes  Configurable
Attach explanation if "Sometimes" or "Configurable" was checked for any operation.
