CET PMC-53A User Manual

CET Electric Technology
92
DNP V3.0
Reports Binary Input Change Events when no specific
variation requested:
 Never
 Only time-tagged
 Only non-time-tagged
 Configurable to send time-tagged or non-time-
tagged
Reports time-tagged Binary Input Change Events when no
specific variation requested:
 Never
 Binary Input Change with Time
 Binary Input Change with Relative Time
 Configurable to send Binary Input Change With
Time and Binary Input Change With Relative
Time
Sends Unsolicited Responses:
 Never
 Configurable - enable/disable
 Only certain objects
 Sometimes (attach explanation)
 ENABLE/DISABLE UNSOLICITED Function codes
supported
Sends Static Data in Unsolicited Responses:
 Never
 When Device Restarts
 When Status Flags Change
No other options are permitted.
Default Counter Object/Variation:
 No Counters Reported
 Configurable
 Default Object
Default Variation:
 Point-by-point list attached
Counters Roll Over at:
 No Counters Reported
 Configurable
 16 Bits
 32 Bits
 Other Value: ______
 Point-by-point list attached
Sends Multi-Fragment Responses
 Yes
 No
 Configurable
Sequential File Transfer Support:
Append File Mode  Yes  No
Custom Status Code Strings  Yes  No
Permissions Field  Yes  No
File Events Assigned to Class  Yes  No
File Events Send Immediately  Yes  No
Multiple Blocks in a Fragment  Yes  No
Max. Number of Files Open: 0
Level 1 Implementation (DNP-L1)
OBJECT
REQUEST
(slave must parse)
RESPONSES
(master must parse)
Obj
Var
Description
Func Codes
(dec)
Qual Code
(hex)
Func Codes
(dec)
Qual Code
(hex)
1
2
Binary Input Status with Flag
1
0x06
129
0x00
10
2
Binary Output Status
1
0x06
129
0x00
12
1
Control Relay Output Block
3,4,5
0x28
129
0x28
20
5
32-Bit Binary Counter without Flag
1
0x06
129
0x00
20
6
16-Bit Binary Counter without Flag
1
0x06
129
0x00
30
3
32-Bit Analog Input without Flag
1
0x06
129
0x00
40
2
16-BIT ANALOG OUTPUT STATUS
1
0x06
129
0x00
41
2
16-BIT ANALOG OUTPUT BLOCK
3,4,5
0x28
129
0x28
50
1
Date and Time
1
0x07
129
0x07
60
1
Class 0 Data
1
0x06
129
80
1
Internal Indicator
2
0x00
129
N/A
N/A
Cold Restart (respond Obj. 52:2)
13
N/A
129
0x07
