CET PMC-53A User Manual

CET Electric Technology
75
5.12.2 Season
The PMC-53A has two sets of Season setup parameters, one for each TOU. The Base Addresses for the
two sets are 7100 and 8100, respectively, where the Register Address = Base Address + Offset. For
example, the register address for TOU #1’s Season #2’s Start Date is 7100+4 = 7104.
Offset
Property
Description
Format
Range/Default*
0
RW
Season #1: Start Date
UINT16
0x0101*
1
RW
Season #1: Weekday#1 Daily Profile
UINT16
0* to 19
2
RW
Season #1: Weekday#2 Daily Profile
UINT16
3
RW
Season #1: Weekday#3 Daily Profile
UINT16
4
RW
Season #2: Start Date
UINT16
High-order Byte: Month
Low-order Byte: Day
5
RW
Season #2: Weekday#1 Daily Profile
UINT16
0* to 19
6
RW
Season #2: Weekday#2 Daily Profile
UINT16
7
RW
Season #2: Weekday#3 Daily Profile
UINT16
8
RW
Season #3: Start Date
UINT16
See Season #2: Start Date
9
RW
Season #3: Weekday#1 Daily Profile
UINT16
0* to 19
10
RW
Season #3: Weekday#2 Daily Profile
UINT16
11
RW
Season #3: Weekday#3 Daily Profile
UINT16
12
RW
Season #4: Start Date
UINT16
See Season #2: Start Date
13
RW
Season #4: Weekday#1 Daily Profile
UINT16
0* to 19
14
RW
Season #4: Weekday#2 Daily Profile
UINT16
15
RW
Season #4: Weekday#3 Daily Profile
UINT16
16
RW
Season #5: Start Date
UINT16
See Season #2: Start Date
17
RW
Season #5: Weekday#1 Daily Profile
UINT16
0* to 19
18
RW
Season #5: Weekday#2 Daily Profile
UINT16
19
RW
Season #5: Weekday#3 Daily Profile
UINT16
20
RW
Season #6: Start Date
UINT16
See Season #2: Start Date
21
RW
Season #6: Weekday#1 Daily Profile
UINT16
0* to 19
22
RW
Season #6: Weekday#2 Daily Profile
UINT16
23
RW
Season #6: Weekday#3 Daily Profile
UINT16
24
RW
Season #7: Start Date
UINT16
See Season #2: Start Date
25
RW
Season #7: Weekday#1 Daily Profile
UINT16
0* to 19
26
RW
Season #7: Weekday#2 Daily Profile
UINT16
27
RW
Season #7: Weekday#3 Daily Profile
UINT16
28
RW
Season #8: Start Date
UINT16
See Season #2: Start Date
29
RW
Season #8: Weekday#1 Daily Profile
UINT16
0* to 19
30
RW
Season #8: Weekday#2 Daily Profile
UINT16
31
RW
Season #8: Weekday#3 Daily Profile
UINT16
32
RW
Season #9: Start Date
UINT16
See Season #2: Start Date
33
RW
Season #9: Weekday#1 Daily Profile
UINT16
0* to 19
34
RW
Season #9: Weekday#2 Daily Profile
UINT16
35
RW
Season #9: Weekday#3 Daily Profile
UINT16
36
RW
Season #10: Start Date
UINT16
See Season #2: Start Date
37
RW
Season #10: Weekday#1 Daily Profile
UINT16
0* to 19
38
RW
Season #10: Weekday#2 Daily Profile
UINT16
39
RW
Season #10: Weekday#3 Daily Profile
UINT16
40
RW
Season #11: Start Date
UINT16
See Season #2: Start Date
41
RW
Season #11: Weekday#1 Daily Profile
UINT16
0* to 19
42
RW
Season #11: Weekday#2 Daily Profile
UINT16
43
RW
Season #11: Weekday#3 Daily Profile
UINT16
44
RW
Season #12: Start Date
UINT16
See Season #2: Start Date
45
RW
Season #12: Weekday#1 Daily Profile
UINT16
0* to 19
46
RW
Season #12: Weekday#2 Daily Profile
UINT16
47
RW
Season #12: Weekday#3 Daily Profile
UINT16
Table 5-45 Season Setup
Notes:
1) Start Date for Season #1 is Jan. 1
st
and cannot be modified.
2) Setting a Season’s Start Date as 0xFFFF terminates the TOU’s Season settings. All subsequent
Seasons’ setup parameters will be ignored since the previous Season’s duration is from its Start
Date to the end of the year.
3) The Start Date of a particular Season must be later than the previous Season’s.
