CET PMC-53A User Manual

CET Electric Technology
56
1316
RO
Ic TDD Even
Float
1318
RO
Ia K-factor
Float
-
1320
RO
Ib K-factor
Float
1322
RO
Ic K-factor
Float
1324
RO
Ia Crest-factor
Float
1326
RO
Ib Crest-factor
Float
1328
RO
Ic Crest-factor
Float
1330
RO
Voltage Unbalance
Float
1332
RO
Current Unbalance
Float
Table 5-10 Power Quality Measurements
5.4.2 Current Harmonic Measurements
Register
Property
Description
Format
Scale
Unit
1400
RO
Ia THD
Float
x1
%
(0.1 means 10%)
1402
RO
Ib THD
Float
1404
RO
Ic THD
Float
1406
RO
Ia TOHD
Float
1408
RO
Ib TOHD
Float
1410
RO
Ic TOHD
Float
1412
RO
Ia TEHD
Float
1414
RO
Ib TEHD
Float
1416
RO
Ic TEHD
Float
1418
RO
Ia HD02
Float
1420
RO
Ib HD02
Float
1422
RO
Ic HD02
Float
1424~1590
RO
…
Float
1592
RO
Ia HD31
Float
1594
RO
Ib HD31
Float
1596
RO
Ic HD31
Float
Table 5-11 Current Harmonic Measurements
5.4.3 Voltage Harmonic Measurements
Register
Property
Description
Format
Scale
Unit
1600
RO
Uan/Uab THD
Float
x1
%
(0.1 means 10%)
1602
RO
Ubn/Ubc THD
Float
1604
RO
Ucn/Uca THD
Float
1606
RO
Uan/Uab TOHD
Float
1608
RO
Ubn/Ubc TOHD
Float
1610
RO
Ucn/Uca TOHD
Float
1612
RO
Uan/Uab TEHD
Float
1614
RO
Ubn/Ubc TEHD
Float
1616
RO
Ucn/Uca TEHD
Float
1618
RO
Uan/Uab HD02
Float
1620
RO
Ubn/Ubc HD02
Float
1622
RO
Ucn/Uca HD02
Float
1624~1790
RO
…
Float
1792
RO
Uan/Uab HD31
Float
1794
RO
Ubn/Ubc HD31
Float
1796
RO
Ucn/Uca HD31
Float
Table 5-12 Voltage Harmonic Measurements
Notes:
1) When the Wiring Mode is 3P3W or 1P2W L-L, the phase A/B/C Voltage THD/TOHD/TEHD/HDxx
mean phase AB/BC/CA Voltage THD/TOHD/TEHD/HDxx.
2) When the Wiring Mode is 1P2W L-N or 1P2W L-L, the L2 and L3 phase voltages
THD/TOHD/TEHD/HDxx have no meaning, and their registers are reserved. When the Wiring
Mode is 1P3W L-N, the L3 phase voltages THD/TOHD/TEHD/HDxx have no meaning, and their
registers are reserved.
5.5 Demands
