CET PMC-53A User Manual

CET Electric Technology
90
26
PFb
1
72
dPFc
27
PFc
1
73
Uan Angle
3
°
28
PF Total
74
Ubn Angle
3
29
Frequency
Hz
75
Ucn Angle
3
30
Neutral Current
(Calculated)
A
76
Ia Angle
31
I4 (Optional
Measurement)
A
77
Ib Angle
32
kWh Import
kWh
78
Ic Angle
33
kWh Export
79
Operating Time
h
34
kWh Total
80
Interval kWh Import
4
kWh
35
kWh Net
81
Interval kWh Export
4
36
kvarh Import
kvarh
82
Interval kvarh Import
4
kvarh
37
kvarh Export
83
Interval kvarh Export
4
38
kvarh Total
84
Interval kVAh
4
kVAh
39
kvarh Net
85
DI #1 Counter
40
kVAh
kVAh
86
DI #2 Counter
41
kW Total Demand
kW
87
DI #3 Counter
42
kvar Total Demand
kvar
88
DI #4 Counter
43
kVA Total Demand
kVA
89
DI #5 Counter
44
Ia Demand
A
90
DI #6 Counter
45
Ib Demand
91
Clear
5
46
Ic Demand
Notes:
1) When the Wiring Mode is 3P3W, the per phase line-to-neutral voltages, kWs, kvars, kVAs and PFs
have no meaning, and their ADF points are reserved.
2) Uan/Ubn/Ucn THD = Uab/Ubc/Uca THD in 3P3W Wiring Mode and represent the harmonics of the
line voltages.
3) Uan/Ubn/Ucn Angle = Uab/Ubc/Uca Angle in 3P3W Wiring Mode and represent the phase angles
of the line voltages.
4) Interval Energy Period (EN Period) can be modified via the Front Panel.
5) The Command register, ADF point 91, is used to reset groups of accumulated values held in the
device. The following table illustrates the override values written to the Command register and
their corresponding actions. It is not essential to release the Command Register for the reset to
operate. The last Command (156003) is reserved, and the device will respond with 0 if received.
Override Value for Command Register
Action
156001
All Energy values
156002
All Demand values
156003
Reserved
