98
97
∑kW Peak Demand of Last Month (Before Last Reset)
INT32
x1
W
98
∑kvar Peak Demand of Last Month (Before Last Reset)
INT32
var
99
∑kVA Peak Demand of Last Month (Before Last Reset)
INT32
VA
Notes:
1) When the Wiring Mode is 1P2W L-N or 1P2W L-L, the L2 and L3 phase voltages and currents have no meaning, and their
registers are reserved.
2) When the Wiring Mode is 1P2W L-N, 1P2W L-L or 1P3W, the Sequence Components U1/I1, U2/I2 and U0/I0 have no
meaning and their registers are reserved.
Object 40 - Analog Output Status Objects
Read with Object 40, Variation 2, and Qualifier 6.
Point
Property
Description
Format
Range
0
RO
Class 0 Points
UINT16
0-65535
Object 41 - Analog Output Command Objects
Responds to Function Codes: 03 (Select), 04 (Operate) and 05 (Direct Operate), Variation 2, Qualifier
0x28, with a Count of 1 only.
Point
Property
Description
Format
Range
0
WO
Class 0 Points
UINT16
0-65535
Note: The following table illustrates the details of Bit Values for Class 0 Points.
Bit Point
Descriptions
Value
Bit 0
Object 1 - Binary Input Status Included in Class 0 responses?
0=No, 1=Yes (default)
Bit 1
Object 10 - Binary Output States Included in Class 0 responses?
0=No, 1=Yes (default)
Bit 2
Object 20 - 32 BIT Binary Counters Included in Class 0 responses?
0=No, 1=Yes (default)
Bit 3
Object 20 - 16 BIT Binary Counters Included in Class 0 responses?
0=No, 1=Yes (default)
Bit 4
Object 30 -Analog Inputs Included in Class 0 responses?
0=No, 1=Yes (default)
Bit 5
Object 40 - Analog Output Status Included in Class 0 responses?
0=No, 1=Yes (default)
Bit 6- Bit 15
Reserved
Object 50 - Date and Time
Read and Write function is supported for this object, which occupies 6 bytes for the device's time. The
time shows the number of UNIX milliseconds since 00:00:00 January 1, 1970, calculated by UNIX
seconds*1000 + milliseconds.
Object 60 - Class Objects
Read with Function Code 1, Variation 1, and Qualifier 6. Only Class 0 polls are supported.
Object 80 - Internal Indicator
This is a Write Only function. Clear the Restart Bit with Function Code 2, Variation 1, Qualifier 0.
Point
Description
Format
Range
7
Device Restart
UINT8
0-1
