CET PMC-53A User Manual

CET Electric Technology
97
31
Ubn/Ubc (3P3W) Angle
INT32
32
Ucn/Uca (3P3W) Angle
INT32
33
Ia Angle
INT32
34
Ib Angle
INT32
35
Ic Angle
INT32
36
In (Calculated)
INT32
x1000
A
37
I4
INT32
38
Ir
INT32
39
Displacement PFa
INT32
x1000
-
40
Displacement PFb
1
INT32
41
Displacement PFc
1
INT32
42
Displacement PF Total
INT32
43
AI Scaled
INT32
x1
-
44
RTD 1
INT32
x100
︒C
45
RTD 2
INT32
46
AO
INT32
x1
-
47
Device Operating Time
INT32
x10
h
48
Phase A Fundamental kW
INT32
x1
W
49
Phase B Fundamental kW
1
INT32
50
Phase C Fundamental kW
1
INT32
51
Fundamental kW Total
INT32
52
Total Harmonic kW
INT32
53
Uan/Uab Fundamental
INT32
x100
V
54
Ubn/Ubc Fundamental
INT32
55
Ucn/Uca Fundamental
INT32
56
Ia Fundamental
INT32
x1000
A
57
Ib Fundamental
1
INT32
58
Ic Fundamental
1
INT32
59
U1 (+ve Sequence Voltage)
2
INT32
x100
V
60
U2 (-ve Sequence Voltage)
2
INT32
61
U0 (Zero Sequence Voltage)
2
INT32
62
I1 (+ve Sequence Current)
2
INT32
x1000
A
63
I2 (-ve Sequence Current)
2
INT32
64
I0 (Zero Sequence Current)
2
INT32
65
Ia TDD
INT32
x100
-
66
Ib TDD
INT32
67
Ic TDD
INT32
68
Ia K Factor
INT32
69
Ib K Factor
INT32
70
Ic K Factor
INT32
71
Ia Crest-factor
INT32
72
Ib Crest-factor
INT32
73
Ic Crest-factor
INT32
74
Voltage Unbalance
INT32
75
Current Unbalance
INT32
76
Uan/Uab THD
INT32
77
Ubn/Ubc THD
INT32
78
Ucn/Uca THD
INT32
79
Ia THD
INT32
80
Ib THD
INT32
81
Ic THD
INT32
82
Ia Present Demand
INT32
x1000
A
83
Ib Present Demand
INT32
84
Ic Present Demand
INT32
85
∑kW Present Demand
INT32
x1
W
86
∑kvar Present Demand
INT32
var
87
∑kVA Present Demand
INT32
VA
88
Ia Peak Demand of This Month (Since Last Reset)
INT32
x1000
A
89
Ib Peak Demand of This Month (Since Last Reset)
INT32
90
Ic Peak Demand of This Month (Since Last Reset)
INT32
91
∑kW Peak Demand of This Month (Since Last Reset)
INT32
x1
W
92
∑kvar Peak Demand of This Month (Since Last Reset)
INT32
var
93
∑kVA Peak Demand of This Month (Since Last Reset)
INT32
VA
94
Ia Peak Demand of Last Month (Before Last Reset)
INT32
x1000
A
95
Ib Peak Demand of Last Month (Before Last Reset)
INT32
96
Ic Peak Demand of Last Month (Before Last Reset)
INT32
