CET Electric Technology
96
Notes:
1) If the Device Model does not support DI, all DI Pulse Counters would be set to “0”.
2) If 4xDIs are supported on the Device Model, DI5 and DI6 Pulse Counter would be set to “0”.
Object 20 - 16-BIT Binary Counters - Primary Readings (Included in Class 0 responses)
Read with Object 20, Variation 6, and Qualifier 6.
Scale for Energy and Operating Time
Scale for Current, PF, I Seq., I Fund., and I Demand
Scale for U, Freq, Phase Angle, RTD, U Fund., U Seq.,
THD, TDD, K Factor, Crest-factor and Unbalance
Scale for AI, AO, Power and Power Demand
Notes:
1) The read-out value 10000 represents the Version is V1.00.00.
2) The following table illustrates the details of Feature Code. Bit 6 and Bit 9 to Bit 15 for the Byte are reserved. Points for I4,
AI Scaled, RTD1, RTD2 and AO in Object 30 are only meaningful if the meter is equipped with the corresponding option.
Bit 7 to Bit 8 (Basic I/O Function)
Bit 3 to Bit 5 (Expansion Module B)
Bit 0 to Bit 2 (Expansion Module A)
00=4xDI+2xDO
01=None
10=4xDI+2xSS Pulse Output
000=None
001=1xAI + 1xAO
010=2xDI + 2xDO
011=2xRTD
100=2xDI + 2x SS Pulse Output
101=Reserved
000=None
001=RS485
010=I4
011=SPI
Object 30 - Analog Inputs Primary Readings (Included in Class 0 responses)
Read with Object 30, Variation 3, and Qualifier 6.
