CET Electric Technology
95
CTc polarity may be reversed (3P4W only)
Supported Flags:
Bit 0 (ONLINE):
0 = Offline, which represents that the control of the Output could not be implemented.
1 = Online, which represents that the Output works properly, once control request has been sent, the command could be
correctly implemented.
Bit 7 (STATE): 0=Off, 1=On
Object 12 - Control Relay Outputs
Responds to Function Codes: 03 (Select), 04 (Operate) and 05 (Direct Operate), Variation 1, Qualifier
0x28, with a Count of 1 only. Only one control object at a time may be specified.
Clear All Energy Registers
Clear Present Monthly Energy Log
Clear Peak Demand of This Month (Since Last Reset)
Clear All Demand Registers
Clear Max/Min Logs of This Month (Since Last Reset)
Clear Device Operating Time
Please refer to the DNP V3.00 Data Object Library document for a detailed description of the Object
Coding format for the Control Relay Output Block as well as the meanings of the returned Status.
Object 20 - 32-BIT Binary Counters - Primary Readings (Included in Class 0 responses)
Read with Object 20, Variation 5, and Qualifier 6.
