Page #94 background imageLoading...
Page #94 background image
CET Electric Technology
94
DNP Point Map
Object 1 - Binary Input Status with Flags (Included in Class 0 responses)
Read with Object 1, Variation 2, and Qualifier 6.
Point
Description
Format
Range
0
DI1
1
UINT8
Bit Flags
1
DI2
1
UINT8
Bit Flags
2
DI3
1
UINT8
Bit Flags
3
DI4
1
UINT8
Bit Flags
4
DI5
1,2
UINT8
Bit Flags
5
DI6
1,2
UINT8
Bit Flags
Supported Flags:
Bit 0 (ONLINE): 0=Offline, 1=Online
Bit 7 (STATE): 0=Off, 1=On
Notes:
1) If the Device Model does not support DI, the Bit 0 and Bit 7 for the bytes of all DI status above would be set to “0”.
2) If 4xDIs are supported on the Device Model, the Bit 0 and Bit 7 in bytes for DI5 and DI6 status would be set to “0”.
Object 10 - Binary Output States (Included in Class 0 responses)
Read with Object 10, Variation 2, and Qualifier 6.
Point
Description
Format
Range
0
Clear Present Energy Log
UINT8
Always 0
1
Clear All Energy Registers
UINT8
Always 0
2
Clear Present Monthly Energy Log
UINT8
Always 0
3
Clear Peak Demand of This Month (Since Last Reset)
UINT8
Always 0
4
Clear All Demand Registers
UINT8
Always 0
5
Clear Max/Min Logs of This Month (Since Last Reset)
UINT8
Always 0
6
Clear All Max./Min. Log
UINT8
Always 0
7
Clear Device Operating Time
UINT8
Always 0
8
Clear All Data
UINT8
Always 0
9
Clear DI1 Pulse Counter
UINT8
Always 0
10
Clear DI2 Pulse Counter
UINT8
Always 0
11
Clear DI3 Pulse Counter
UINT8
Always 0
12
Clear DI4 Pulse Counter
UINT8
Always 0
13
Clear DI5 Pulse Counter
UINT8
Always 0
14
Clear DI6 Pulse Counter
UINT8
Always 0
15
Clear All Pulse Counters
UINT8
Always 0
16
DO1
1
UINT8
Bit Flags
17
DO2
1
UINT8
Bit Flags
18
DO3
1,2
UINT8
Bit Flags
19
DO4
1,2
UINT8
Bit Flags
20-29
Reserved
30-43
Wiring Diagnostics Status
UINT8
Bit Flags
Notes:
1) If the Device Model does not support DO, the Bit 0 and Bit 7 for the bytes of all DO status above would be set to “0”.
2) If 2xDOs are supported on the Device Model, the Bit 0 and Bit 7 in bytes for DO3 and DO4 status would be set to “0”.
3) The following table shows the details of Point 30-43.
No.
Event
30
Frequency is out of range (45 to 65Hz) (3P4W or 3P3W)
31
Any phase voltage < 10% of PT Primary (Register 6000) (3P4W only)
32
Any phase current < 10% of CT Primary (Register 6004) (3P4W or 3P3W)
33
RTD 1 broken (RTD Input option only)
34
RTD 2 broken (RTD Input option only)
Voltage Phase Reversal (3P4W only)
Current Phase Reversal (3P4W or 3P3W)
Negative kW Total may be abnormal (3P4W or 3P3W)
Negative kWa is may be abnormal (3P4W only)
Negative kWb may be abnormal (3P4W only)
Negative kWc may be abnormal (3P4W only)
CTa polarity may be reversed (3P4W only)
CTb polarity may be reversed (3P4W only)
