CET PMC-53A - Page 85

CET Electric Technology
85
(3)
R/W
APDU_Timeout
0~65535
3000
R/W
Number_Of_APDU_Retries
0~255
3
R/W
Max_Master
1 to 127
127
R/W
Max_Info_Frame
1
R
Device_Address_Binding
{}
R
Database_Revision
0
R
Local_Time
Configuration by
timing
12:00:00:00
R
Local_Date
Configuration by
timing
2016.07.01
*
R = Read Only; R/W = Read/Write
Notes:
1) Supported services:
o ReadProperty
o ReadPropertyMultiple
o WriteProperty
o TimeSynchronization
o Who-Has
o Who-Is, I-Am, I-Have
2) Supported object types:
o Analog-Input
o Analog-Value
o Binary-Input
o Binary-Output
o Device
3) Analog Input Objects (PMC-53A’s Real-Time Parameters)
Optional Properties Supported: Description, Reliability
Use the Present_Value property of the Analog_Input objects for all read-only numeric variables
in PMC-53A. These objects support the Description and Reliability optional properties and all
required Analog_Input object properties. None of them are writable. The values that are not
instantaneous (i.e. Accumulated Energy, Peak Demand) are non-volatile.
Register
Description
Property
Unit
Range
AI 0000
Uan
1
R
V
AI 0002
Ubn
1
R
AI 0004
Ucn
1
R
AI 0006
ULN average
1
R
AI 0008
Uab
R
AI 0010
Ubc
R
AI 0012
Uca
R
AI 0014
ULL average
R
AI 0016
Ia
R
A
AI 0018
Ib
R
AI 0020
Ic
R
AI 0022
I average
R
AI 0024
kWa
1
R
kW
AI 0026
kWb
1
R
AI 0028
kWc
1
R
AI 0030
kW Total
R
AI 0032
kvara
1
R
kvar
AI 0034
kvarb
1
R
AI 0036
kvarc
1
R
AI 0038
kvar Total
R
AI 0040
kVAa
1
R
kVA
