Emotron VS Series Quick Start Guide
- 32 -
Table 3-7 Numbers of terminal of VSS/VSR series
Model
VSS
VSR
0.4~2.2kW
4~7.5kW
DI
5 (DI1~DI4,DI7)
5 (DI1~DI4,DI7)
7 (DI1~DI7)
Do
1 (Y1)
1 (Y1)
2 (Y1,Y2)
AI
2 (AI1,AI2)
2 (AI1,AI2)
3 (AI1,AI2,AI3)
AO
1 (AO1)
1 (AO1)
2 (AO1,AO2)
RO
1 (R1)
1 (R1)
2 (R1,R2)
RS485
1 (485+,485-)
1 (485+,485-)
1 (485+,485-)
Table 3-8 Numbers of terminal of VSM/VSX series
Model
VSM
VSX
0.4~2.2kW
4~22kW
DI
5 (DI1~DI4,DI7)
5 (DI1~DI4,DI7)
7 (DI1~DI7)
Do
1 (Y1)
1 (Y2/HO)
2 (Y1,Y2)
AI
2 (AI1,AI2)
2 (AI1,AI2)
3 (AI1,AI2,AI3)
AO
1 (AO1)
2 (AO1,AO2)
2 (AO1,AO2)
RO
1 (R1)
2 (R1, R2)
2 (R1,R2)
RS485
1 (485+,485-)
1 (485+,485-)
1 (485+,485-)
Table 3-9 Description of control circuit terminals
Type
Terminal
Name
Function Description
Power supply
+10V-GND
External +10 V
power supply
Provide +10 V power supply to
external unit.
Generally, it provides power supply to
external potentiometer with resistance
range of 1–5 kΩ.
Maximum output current: 10 mA
+24V-COM
External +24V
power
supply Applying
to Overvoltage
Category II
circuit
Provide +24 V power supply to
external unit.
Generally, it provides power supply to
DI/Do terminals and external sensors.
Maximum output current: 200 mA
PLC
Input terminal
of
external power
supply
Connect to +24 V by default.
When DI1-DI7 need to be driven by
external signal, PLC needs to be
connected to external power supply
and be disconnected from +24 V.
Analog input
AI1-GND
Analog input 1
Input voltage range: DC 0～10V/0～
20mA，decided by toggle switches
AI1, AI2 on the control board
Impedance: 250 kΩ (voltage input),
250 Ω (current input)
AI2-GND
Analog input 2
AI3-GND
(VSX Only)
Analog input 3
Input Voltage Range: DC -10～+10V
Input impedance:250kΩ
Switch input
DI1 – 24V
Switch input
terminals 1
Maximum input frequency:200Hz
Impedance:2.4kΩ
Voltage range for level input:9V～30V
DI2 – 24V
Switch input
terminals 2
DI3 – 24V
Switch input
terminals 3
DI4 – 24V
Switch input
terminals 4
