CG VSR239p5 - Page 34

Emotron VS Series Quick Start Guide
- 33 -
DI5 – 24V
(VSX Only)
Switch input
terminals 5
DI6 – 24V
(VSX Only)
Switch input
terminals 6
DI7/HI-24V
Switch input
terminals 7 OR
High-speed
pulse input
Besides features of DI1–DI6, it can be
used for high-speed pulse input.
Maximum input frequency: 100 kHz
Analog
output
AO1-GND
Analog output
terminal 1
Output voltage range: DC 0～10V/0～
20mA，decided by toggle switches
AO1, AO2 on the control board
Impedance requirements≥10kΩ
AO2-GND
(VSX Only)
Analog output
terminal 2
Switch output
Y1-COM
Open collector
output 1
Voltage range:0～24V
Current range:0～50mA
Y2/HO-COM
(VSX Only)
Open collector
output 2 OR
High-speed
pulse output
Besides features of Y1, it can be used
for High-speed pulse output channels.
The maximum out put
frequency:100kHz
Relay output
R1A-R1C
Normally open
terminal
Contact driving capacity:
AC250V，3A，COSØ=0.4.
DC 30V，1A
R1B-R1C
Normally
closed terminal
R2A-R2C
(VSX Only)
Normally open
terminal
R2B-R2C
(VSX Only)
Normally
closed terminal
485
Communication
485+-485-
485
Communication
Terminals
Rate:
4800/9600/19200/38400/57600/
115200bps
Termination resistor is set by the
toggle switch on the control panel
RS485
GND
485
Communication
shielded
ground
Shield
PE
Shield Ground
Ground terminal for shield
Auxiliary
Interface
External
operation
panel interface
Use standard network cable
Maximum cable distance: 50m
UP/DOWNLOAD
Parameter
copy interface
