Emotron VS Series Quick Start Guide
- 49 -
A0.07
Motor Selection
0: Motor 1
0
×
1: Motor 2
A0.08
Motor control mode
Unit’s place: Motor 1 control mode
0: Voltage/Frequency (V/F)
control
1: Sensor-less vector control 1
2: Sensor-less vector control 2
01
×
Ten’s place: Motor 2 control mode
0: Voltage/Frequency (V/F)
control
1:Sensor-less vector control 1
2: Sensor-less vector control 2
A0.09
DI7/HI input mode
0: Digital input terminal 7
0
×
1: Pulse input
A0.10
AI1\AI2\AI3 input mode
Unit's place: AI1
0: Analog input
1: Digital input
000
×
Ten’s place: AI2
(same as AI1)
Hundred’s place: AI3 (VSX Only)
(same as AI1)
A0.11
Y2/HO input mode
0: Digital 0utput terminal 2
0
×
1: Pulse output
A0.12
PWM optimization
Unit's place: PWM modulation mode
0: Fixed carrier
1: Random carrier
2: Derating of fixed carrier
3: Derating of random carrier
100
×
Ten’s place: PWM modulation mode
0: Seven-segment mode
1: Five-segment mode
2: Five-segment and
seven-segment automatic
switchover
Hundred’s place: over-modulation
adjustment
0: Disabled
1: Enabled
A0.13
Carrier frequency
0.700～16.000kHz
Model
defined
△
A0.14
Upper carrier
frequency
0.700～16.000kHz
8.000kHz
×
A0.15
Lower carrier
frequency
0.700～16.000kHz
2.000kHz
×
A0.16
Output voltage
5.0～150.0%
100.0%
×
A0.17
AVR
0: Disabled
1
×
1: Enabled
2: AVR is disabled if the DC
bus voltage > the rated
voltage of DC bus, and it will be
enabled if the DC bus voltage ≤ the
rated voltage of DC bus.
A0.18
Fan control
0: Run at power-on
1
×
1: Fan working during running
A0.19
Factory password
0～99999
0
×
