Emotron VS Series Quick Start Guide
- 53 -
(VSX Only)
07: Fault reset (RESET)
08: Running suspended
09: External fault input
10: Terminal UP
11: Terminal DOWN
12: UP/DOWN (including ∧/∨
key) adjustment clear
13: Multi-step frequency terminal 1
14: Multi-step frequency terminal 2
15: Multi-step frequency terminal 3
16: Multi-step frequency terminal 4
17: Accel/Decel time determinant 1
18: Accel/Decel time determinant 2
19: Accel/Decel disabled
(ramp stop not inclusive)
20: Switch to auxiliary speed
Setting
21: PLC status reset
22: Simple PLC paused
23: PID paused
24: PID adjustment direction
25: PID integration paused
26: PID parameter switch
27: Swing frequency pause(output
the current frequency)
28: Swing frequency reset(output
the central frequency)
29: Run command switched to
keypad control
30: Run command switched to
terminal control
31: Run command switched to
communication control
32: Count input
33: Count clear
34: Length count
35: Length clear
36: DC brake input command at
Stop
37: Speed/torque control switch
38: PID reset
39: Disable reverse running
40: Disable forward running
C0.06
Function of terminal DI7
0
×
C0.07
Function of terminal AI1
0
×
C0.08
Function of terminal AI2
0
×
C0.09
Function of terminal AI3
(VSX Only)
0
×
C0.10
Filtering time of digital
input terminal
0.000～1.000s
0.010s
△
C0.11
Delay time before terminal
DI1 is valid
0.0～300.0s
0.0s
△
C0.12
Delay time before terminal
DI2 is valid
0.0～300.0s
0.0s
△
C0.13
Terminal DI1～DI5
positive/negative logic
DI5, DI4, DI3, DI2, DI1
00000
×
0: Positive logic(Terminals are on at
0V/off at 24V)
1: Negative Logic (Terminals are off
at 0V/on at 24V)
C0.14
Terminal DI6～AI3
positive/negative logic
AI3, AI2, AI1, DI7, DI6
00000
×
0: Positive logic
1: Negative Logic
C0.15
FWD/REV terminal
0: Two-wire mode 1
0
×
