d0.16
Stator resistance of PMSM
0.001～65.535Ω
Model
Defined
×
d0.17
D-axis inductance of
PMSM
0.01～655.35mH
Model
Defined
×
d0.18
Q-axis inductance of
PMSM
0.01～655.35mH
Model
Defined
×
d0.19
Back-EMF of PMSM
0～65535V
Model
Defined
×
d0.20
Installation Angle of
Encoder
0.0～359.9°
0.0°
×
d0.21
Motor’s pole number
0～1000
4
⊙
d0.22
Find encoder origin at
beginning
0: Not find
1: Find
1
×
d0.30
Autotuning of motor 1
0: No autotuning
0
×
1: Static autotuning of motor
2: Rotary autotuning of motor
Group d1 V/f Control Parameters of Motor 1
d1.00
V/f curve setting
00: Linear V/F
0
×
01: Multi-stage V/F
02: 1.2nd power V/F
03: 1.4nd power V/F
04: 1.6nd power V/F
05: 1.8nd power V/F
06: 2.0nd power V/F
07: V/F complete separation
(VSX Only)
08: V/F half separation
(VSX Only)
09: 1.2 power inverse curve V/F
(VSX Only)
10: 1.4 power inverse curve V/F
(VSX Only)
11: 1.6 power inverse curve V/F
(VSX Only)
12: 1.8 power inverse curve V/F
(VSX Only)
13: 2.0 power inverse curve V/F
(VSX Only)
d1.01
Torque boost
0.0%–30.0% 0.0% (fixed torque
boost)
0.0%
△
d1.02
Cut-off frequency of torque
boost
0.00～Fmax
50.00Hz
△
d1.03
Multi-point V/F frequency
1(F1)
0.00～d1.05
0.00Hz
△
d1.04
Multi-point V/F voltage 1
(V1)
0.0～100.0
0.0%
△
d1.05
Multi-point V/F frequency
2(F2)
d1.03～d1.07
5.00Hz
△
d1.06
Multi-point V/F voltage 2
(V2)
0.0～100.0
14.0%
△
d1.07
Multi-point V/F frequency
3(F3)
d1.05～d1.09
25.00Hz
△
d1.08
Multi-point V/F voltage 3
(V3)
0.0～100.0
50.0%
△
d1.09
Multi-point V/F frequency
4(F4)
d1.07～600.00Hz
50.00Hz
△
