Emotron VS Series Quick Start Guide
- 59 -
Function selection of virtual
VDO4 terminals output
0 : Internal short circuited to
physical DIx
Other: The same as function code
C1.00
Function selection of virtual
VDO5 terminals output
0 : Internal short circuited to
physical DIx
Other: The same as function code
C1.00
Virtual VDO1 output delay
time
Virtual VDO2 output delay
time
Virtual VDO3 output delay
time
Virtual VDO4 output delay
time
Virtual VDO5 output delay
time
VDO output terminal
positive and negative logic
Group d0 Parameters of Motor 1
0: Three phase asynchronous
motors
2: Single phase asynchronous
motors (Need to remove capacitor)
3: Single phase asynchronous
motors (No need to remove
capacitor)
Rated frequency of
motor 1
Stator resistance R1 of
async motor 1
Rotor resistance R2 of
async motor 1
Leakage inductance L1
of async motor 1
Mutual inductance L2 of
asynchronous motor 1
No-load current of
async motor 1
Field weakening coeff 1
of async motor 1
Field weakening coeff 2
of async motor 1
Field weakening coeff 3
of async motor 1
