Emotron VS Series Quick Start Guide
- 58 -
C3.02
Y2/HO output function
(when used as HO)
(VSX Only)
03: Output current
04: Output voltage
05: Output power
06: Bus voltage
07: +10V
08: keypad potentiometer
09: AI1
10: AI2
11: AI3 (VSX Only)
12: HI
13: Output torque
14: Ao communication given 1
15: Ao communication given 2
3
×
C3.03
AO1 offset
-100.0～100.0%
0.0%
△
C3.04
AO1 gain
-2.000～2.000
1.000
△
C3.05
AO1 filtering time
0.000～10.000s
0.000s
△
C3.06
AO2 offset
(VSX Only)
-100.0～100.0%
0.00%
△
C3.07
AO2 gain
(VSX Only)
-2.000～2.000
1.000
△
C3.08
AO2 filtering time
(VSX Only)
0.000～10.000s
0.000s
△
C3.09
HO maximum output
pulse frequency
(VSX Only)
0.01～100.00kHz
50.00kHz
△
C3.10
HO output filtering time
(VSX Only)
0.000～10.000s
0.010s
△
Group C4 Virtual IO
C4.00
Function selection of virtual
VDI1 terminal
The same as function code C0.00
0
×
C4.01
Function selection of virtual
VDI2 terminal
The same as function code C0.00
0
×
C4.02
Function selection of virtual
VDI3 terminal
The same as function code C0.00
0
×
C4.03
Function selection of virtual
VDI4 terminal
The same as function code C0.00
0
×
C4.04
Function selection of virtual
VDI5 terminal
The same as function code C0.00
0
×
C4.05
Valid status setting mode
of virtual VDI terminals
VDI5, VDI4, VDI3, VDI2, VDI1
00000
×
0:Validity of VDI depends on virtual
VDOx’s status
1:Validity of VDI set by function
code C4.06
C4.06
Settings of virtual VDI
terminal status
VDI5, VDI4, VDI3, VDI2, VDI1
00000
△
0: Invalid
1: Valid
C4.07
Function selection of virtual
VDO1 terminals output
0 : Internal short circuited to
physical DIx
Other: The same as function code
C1.00
0
△
C4.08
Function selection of virtual
VDO2 terminals output
0 : Internal short circuited to
physical DIx
Other: The same as function code
C1.00
0
△
C4.09
Function selection of virtual
VDO3 terminals output
0 : Internal short circuited to
physical DIx
Other: The same as function code
0
△
