CG VSR239p5 - Group C3 Analog and Pulse Output

Emotron VS Series Quick Start Guide
- 57 -
C2.17
Set value corresponding
to minimum input of
curve AI3
(VSX Only)
-100.0～100.0%
-100.0%
△
C2.18
Input of inflection point
1 of curve AI3
(VSX Only)
Minimum input of curve AI1～Input
of inflection point 2 of curve AI3
25.0%
△
C2.19
Set value corresponding
to input of inflection
point 1 of curve AI3
(VSX Only)
-100.0～100.0%
-50.0%
△
C2.20
Input of inflection point
2 of curve AI3
(VSX Only)
Input of inflection point 1 of curve
AI3～Maximum input of curve AI3
75.0%
△
C2.21
Set value corresponding
to input of inflection
point 2 of curve AI3
(VSX Only)
-100.0～100.0%
50.0%
△
C2.22
Maximum input of curve
AI3
(VSX Only)
Input of inflection point A of curve
AI3～100.0%
100.0%
△
C2.23
Set value corresponding
to maximum input of
curve AI3
(VSX Only)
-100.0～100.0%
100.0%
△
C2.24
Minimum input of curve
keypad potentiometer
0.0～Maximum input of curve
keypad potentiometer
0.5%
△
C2.25
Set value corresponding
to minimum input of
curve keypad
potentiometer
-100.0～100.0%
0.0%
△
C2.26
Maximum input of curve
keypad potentiometer
Minimum input of curve keypad
potentiometer～100.0
99.9%
△
C2.27
Set value corresponding
to maximum input of
curve keypad
potentiometer
-100.0～100.0%
100.0%
△
C2.28
AI1 terminal filtering time
0.000～10.000s
0.100s
△
C2.29
AI2 terminal filtering time
0.000～10.000s
0.100s
△
C2.30
AI3 terminal filtering time
(VSX Only)
0.000～10.000s
0.100s
△
C2.31
Keypad potentiometer
filtering time
0.000～10.000s
0.100s
△
C2.32
Minimum input of curve HI
0.00 kHz～Maximum input of curve
HI
0.00kHz
△
C2.33
Set value corresponding to
minimum input of curve HI
-100.0～100.0%
0.0%
△
C2.34
Maximum input of curve HI
Minimum input of curve HI～
100.00kHz
50.00kHz
△
C2.35
Set value corresponding to
maximum input of curve HI
-100.0～100.0%
100.0%
△
C2.36
HI terminal filtering time
0.000～10.000s
0.100s
△
Group C3 Analog and Pulse Output
C3.00
AO1 output function
00: No output
01: Output frequency
02: Command frequency
1
×
C3.01
AO2 output function
(VSX Only)
2
×
