CG VSR239p5 - Group C2 Analog and Pulse Input

Emotron VS Series Quick Start Guide
- 56 -
C1.16
Accumulative running
time setting
0～60000h 0:Disabled
0h
×
C1.17
Brake control selection
0: Disabled
0
×
1: Enabled
C1.18
Brake opened frequency
Closed frequency ~30.00Hz
2.50Hz
×
C1.19
Brake opened current
0.0~200.0%
0.0%
△
C1.20
Brake open waiting time
0.00~10.00s
0.00s
×
C1.21
Brake open operating time
0.00~10.00s
0.50s
×
C1.22
Brake closed frequency
0.00Hz~opened frequency
2.00Hz
×
C1.23
Brake close waiting time
0.00~10.00s
0.00s
×
C1.24
Brake close operating time
0.00~10.00s
0.50s
×
Group C2 Analog and Pulse Input
C2.00
Minimum input of curve
AI1
0.0%～input of inflection point1
of curve AI1
1.0%
△
C2.01
Set value corresponding
to minimum input of
curve AI1
-100.0～100.0%
0.0%
△
C2.02
Input of inflection point
1 of curve AI1
Minimum input of curve AI1～Input
of inflection point 2 of curve AI1
100.0%
△
C2.03
Set value corresponding
to input of inflection
point 1 of curve AI1
-100.0～100.0%
100.0%
△
C2.04
Input of inflection point
2 of curve AI1
Input of inflection point 1 of curve
AI1～Maximum input of curve AI1
100.0%
△
C2.05
Set value corresponding
to input of inflection
point 2 of curve AI1
-100.0～100.0%
100.0%
△
C2.06
Maximum input of curve
AI1
Input of inflection point 2 of curve
AI1～100.0%
100.0%
△
C2.07
Set value corresponding
to maximum input of
curve AI1
-100.0～100.0%
100.0%
△
C2.08
Minimum input of curve
AI2
0.0%～input of inflection point1 of
curve AI2
1.0%
△
C2.09
Set value corresponding
to minimum input of
curve AI2
-100.0～100.0%
0.0%
△
C2.10
Input of inflection point
1 of curve AI2
Minimum input of curve AI1～Input
of inflection point 2 of curve AI2
100.0%
△
C2.11
Set value corresponding
to input of inflection
point 1 of curve AI2
-100.0～100.0%
100.0%
△
C2.12
Input of inflection point
2 of curve AI2
Input of inflection point 1 of curve
AI2～Maximum input of curve AI2
100.0%
△
C2.13
Set value corresponding
to input of inflection
point 2 of curve AI2
-100.0～100.0%
100.0%
△
C2.14
Maximum input of curve
AI2
Input of inflection point A of curve
AI2～100.0%
100.0%
△
C2.15
Set value corresponding
to maximum input of
curve AI2
-100.0～100.0%
100.0%
△
C2.16
Minimum input of curve
AI3 (VSX Only)
0.0%～input of inflection point1
of curve AI3
0.0%
△
