CG VSR239p5 - Page 64

Emotron VS Series Quick Start Guide
- 63 -
defined
d3.02
Rated voltage of motor 1
60～660V
Model
defined
×
d3.03
Rated current of motor 1
0.1～1500.0A
Model
defined
×
d3.04
Rated frequency of
motor 1
10.00～600.00Hz
Model
defined
×
d3.05
Rated speed of motor 1
1～30000
Model
defined
×
d3.08
Stator resistance R1 of
async motor 1
0.001～65.535Ω
Model
defined
×
d3.09
Rotor resistance R2 of
async motor 1
0.001～65.535Ω
Model
defined
×
d3.10
Leakage inductance L1
of async motor 1
0.01～655.35mH
Model
defined
×
d3.11
Mutual inductance L2 of
asynchronous motor 1
0.1～6553.5mH
Model
defined
×
d3.12
No-load current of
async motor 1
0.1～1500.0A
Model
defined
×
d3.13
Field weakening coeff 1
of async motor 1
0.0～100.0
87%
×
d3.14
Field weakening coeff 2
of async motor 1
0.0～100.0
75%
×
d3.15
Field weakening coeff 3
of async motor 1
0.0～100.0
70%
×
d3.16
Stator resistance of PMSM
0.001～65.535Ω
Model
Defined
×
d3.17
D-axis inductance of
PMSM
0.01～655.35mH
Model
Defined
×
d3.18
Q-axis inductance of
PMSM
0.01～655.35mH
Model
Defined
×
d3.19
Back-EMF of PMSM
0～65535V
Model
Defined
×
d3.20
Installation Angle of
Encoder
0.0～359.9°
0.0°
×
d3.21
Motor’s pole number
0～1000
4
⊙
d3.22
Find encoder origin at
beginning
0: Not find
1: Find
1
×
d3.30
Autotuning of motor 2
0: No autotuning
0
×
1: Static autotuning of motor
2: Rotary autotuning of motor
Group d4 V/f Control Parameters of Motor 2
d4.00
V/f curve setting
00: Linear V/F
0
×
01: Multi-stage V/F
02: 1.2nd power V/F
03: 1.4nd power V/F
04: 1.6nd power V/F
05: 1.8nd power V/F
06: 2.0nd power V/F
07: V/F complete separation
(VSX Only)
08: V/F half separation
(VSX Only)
09: 1.2 power inverse curve V/F
(VSX Only)
10: 1.4 power inverse curve V/F
(VSX Only)
