11: 1.6 power inverse curve V/F
(VSX Only)
12: 1.8 power inverse curve V/F
(VSX Only)
13: 2.0 power inverse curve V/F
(VSX Only)
d4.01
Torque boost
0.0%–30.0% 0.0% (fixed torque
boost)
0.0%
△
d4.02
Cut-off frequency of torque
boost
0.00～Fmax
50.00Hz
△
d4.03
Multi-point V/F frequency
1(F1)
0.00～600.00Hz
0.00Hz
△
d4.04
Multi-point V/F voltage 1
(V1)
0.0～100.0
0.0%
△
d4.05
Multi-point V/F frequency
2(F2)
0.00～600.00Hz
5.00Hz
△
d4.06
Multi-point V/F voltage 2
(V2)
0.0～100.0
14.0%
△
d4.07
Multi-point V/F frequency
3(F3)
0.00～600.00Hz
25.00Hz
△
d4.08
Multi-point V/F voltage 3
(V3)
0.0～100.0
50.0%
△
d4.09
Multi-point V/F frequency
4(F4)
0.00～600.00Hz
50.00Hz
△
d4.10
Multi-point V/F voltage 4
(V4)
0.0～100.0 Ue=100.0%
100.0%
△
d4.11
V/F slip compensation gain
0.0～300.0%
0.0%
△
d4.12
Stator voltagedrop
compensation gain
0.0～200.0%
100.0%
△
d4.13
Excitation boost gain
0.0～200.0%
100.0%
△
d4.14
Oscillation Suppression
0.0～300.0%
100.0%
△
d4.15
Voltage source for V/F
separation
0: Digital setting (d4.16)
0
×
1: keypad potentiometer
2: AI1
3: Multi-reference
4: Pulse setting ( DI7/HI )
5: PID
6: AI2
7: AI3 (VSX Only)
d4.16
Voltage digital setting for
V/F separation
0 V to rated motor voltage
0.0%
△
d4.17
Voltage rise time of V/F
separation
0.0～6000.0s
It indicates the time for the
voltage rising from 0 V to rated
Motor voltage.
0.1s
△
d4.18
Set the IQ filter time below
0.5Hz in VVF mode
1～3000ms
500ms
×
d4.19
Set the IQ filter time above
2Hz in VVF mode
1～3000ms
100ms
×
d4.20
Torque revision when run
forward
0.0～5.0%
0.0%
△
d4.21
Torque revision when run
reverse
0.0～5.0%
1.0%
△
Group d5 Vector Control Parameters of Motor 2
d5.00
Speed/torque control
0: speed control
0
×
1: torque control
