Emotron VS Series Quick Start Guide
- 69 -
(VSX Only)
Group F0 Process PID
F0.00
PID setting
0: F0.01 digital setting
0
×
1:keypad potentiometer
(When using LED keypad)
2: AI1
3: Communication
4: Multi-Reference
5: DI7/HI pulse input
6: AI2
7: AI3 (VSX Only)
F0.01
PID digital setting
0.0～100.0%
50.0%
△
F0.02
PID feedback
0: AI1
0
×
1: AI2
2: Communication
3: AI1+AI2
4: AI1-AI2
5: Max{AI1，AI2}
6: Min{AI1，AI2}
7: DI7/HI pulse input
8: AI3 (VSX Only)
F0.03
PID setting feedback range
0.0～6000.0
100.0
△
F0.04
PID action direction
0: Forward action
0
×
1: Reverse action
F0.05
Filtering time of PID
setting
0.000～10.000s
0.000s
△
F0.06
Filtering time of PID
feedback
0.000～10.000s
0.000s
△
F0.07
Filtering time of PID
output
0.000～10.000s
0.000s
△
F0.08
Proportional gain Kp1
0.0～1000.0
1.0
△
F0.09
Integration time Ti1
0.00～10.00s
0.10s
△
F0.10
Differential time Td1
0.000～10.000s
0.000s
△
F0.11
Proportional gain Kp2
0.0～100.0
1.0
△
F0.12
Integration time Ti2
0.01～10.00s
0.10s
△
F0.13
Differential time Td2
0.000～10.000s
0.000s
△
F0.14
PID parameter switch
0: No switch, determined by
parameters Kp1, Ti1 and Td1
0
×
1: Auto switch on the basis of input
offset
2: Switched by terminal
F0.15
PID parameter switchover
deviation 1
0.0～100.0%
20.0%
×
F0.16
PID parameter switchover
deviation 2
0.0～100.0%
80.0%
×
F0.17
PID offset limit
0.0～100.0%
0.0%
×
F0.18
PID integral property
Unit's place (Whether to stop
integral operation when the output
reaches the limit)
0: Continue integral operation
1: Stop integral operation
00
×
Ten's place (Integral separated)
0: Invalid
1: Valid
