Emotron VS Series Quick Start Guide
- 70 -
F0.19
PID differential limit
0.0～100.0%
0.5%
×
F0.20
PID initial value
0.0～100.0%
0.0%
×
F0.21
Holding time of PID
initial value
0.0～6000.0s
0.0s
×
F0.22
PID output frequency
upper limit
PID output frequency lower limit～
100.0%（100.0% corresponds to
maximum frequency ）
100.0%
×
F0.23
PID output frequency lower
limit
–100.0%～PID output frequency
lower limit
0.0%
×
F0.24
Low value of PID feedback
loss
0.0～100.0%
0.0%: Not judging feedback loss
0.0%
×
F0.25
Detection time for low
value of PID feedback loss
0.0～30.0s
1.0s
×
F0.26
PID operation selection
Unit’s place: PID operation selection
when stop
0:Do not operate when stop
1:Operate when stop
00000
×
Ten’s place: output is limited by
output frequency
0:No limited
1:limited
Hundred’s place: UP/DOWN digital
given of PID
0:Zero clearing when power off
1:Hold when power off
Thousand’s place: PID feedback
loss detection when stop
0:Not detect when stop
1:detect when stop
Ten thousand’s place: action for PID
feedback loss
0:Report fault
1:Ramp to stop
2:Continue running
F0.27
UP/DOWN speed of PID
digital given
0.0～100.0% (0.0% Invalid)
0.0%
△
F0.28
High value of PID feedback
loss
0.1～100.0%
0.0%: Not judging feedback loss
100.0%
×
F0.29
Detection time for high
value of PID feedback loss
0.0～30.0s
1.0s
×
F0.30
PID upper limit source
0: F0.22
1: F0.22*VP
2: F0.22*AI1
3: F0.22*AI2
4: F0.22*HI
5: F0.22*AI3
0
×
F0.31
PID lower limit source
0: F0.23
1: F0.23*VP
2: F0.23*AI1
3: F0.23*AI2
4: F0.23*HI
5: F0.23*AI3
0
×
Group F1: Multi-Reference and Simple PLC Function
F1.00
Reference 0
-100.0～100.0%
0.0%
△
F1.01
Reference 1
-100.0～100.0%
0.0%
△
F1.02
Reference 2
-100.0～100.0%
0.0%
△
