F1.03
Reference 3
-100.0～100.0%
0.0%
△
F1.04
Reference 4
-100.0～100.0%
0.0%
△
F1.05
Reference 5
-100.0～100.0%
0.0%
△
F1.06
Reference 6
-100.0～100.0%
0.0%
△
F1.07
Reference 7
-100.0～100.0%
0.0%
△
F1.08
Reference 8
-100.0～100.0%
0.0%
△
F1.09
Reference 9
-100.0～100.0%
0.0%
△
F1.10
Reference 10
-100.0～100.0%
0.0%
△
F1.11
Reference 11
-100.0～100.0%
0.0%
△
F1.12
Reference 12
-100.0～100.0%
0.0%
△
F1.13
Reference 13
-100.0～100.0%
0.0%
△
F1.14
Reference 14
-100.0～100.0%
0.0%
△
F1.15
Reference 15
-100.0～100.0%
0.0%
△
F1.16
Reference 0 source
0: Digital setting (F1.00)
0
×
1: keypad potentiometer
(When using LED keypad)
2: AI1
3: Process PID output
4: X7/HI pulse input
5: AI2
6: AI3 (VSX Only)
F1.17
Running mode of simple
PLC
Unit's place: PLC running mode
0: Stop after a single cycle
1: Continue to run with the last
frequency after a single cycle
2: Repeat cycles
0000
×
Ten’s place: started mode
0: Continue to run from the step of
stop (or fault)
1: Run from the first step
“multi-step frequency 0”
2: Run from the eighth step
“multi-step frequency 8”
3: Run from the fifteenth step
“multi-step frequency 15”
Hundreds place: power loss
memory
0: Memory disabled on power loss
1: Memory enabled on power loss
Thousands place: unit of simple
PLC running time
0: Second (s)
1: Hour (h)
F1.18
Running time of step 0
0.0～6000.0s(h)
0.0s(h)
△
F1.19
Running time of step 1
0.0～6000.0s(h)
0.0s(h)
△
F1.20
Running time of step 2
0.0～6000.0s(h)
0.0s(h)
△
F1.21
Running time of step 3
0.0～6000.0s(h)
0.0s(h)
△
F1.22
Running time of step 4
0.0～6000.0s(h)
0.0s(h)
△
F1.23
Running time of step 5
0.0～6000.0s(h)
0.0s(h)
△
F1.24
Running time of step 6
0.0～6000.0s(h)
0.0s(h)
△
F1.25
Running time of step 7
0.0～6000.0s(h)
0.0s(h)
△
F1.26
Running time of step 8
0.0～6000.0s(h)
0.0s(h)
△
F1.27
Running time of step 9
0.0～6000.0s(h)
0.0s(h)
△
F1.28
Running time of step 10
0.0～6000.0s(h)
0.0s(h)
△
