Emotron VS Series Quick Start Guide
- 73 -
Ten’s place: select if it can be
reduced to negative
0:Disable
1:Enable
F1.51
UP/DOWN speed of
Multi-reference
0.0～100.0% (0.0%Invalid)
0.0%
△
Group F2: Swing Frequency, Fixed Length , Wakeup and Count
F2.00
Swing frequency setting
mode
0: Relative to the setting
frequency
0
×
1: Relative to the maximum
frequency
F2.01
Swing frequency amplitude
0.0～100.0%
0.0%
△
F2.02
Jump frequency amplitude
0.0～50.0%
0.0%
△
F2.03
Rising Time of Swing
frequency
0.0～6000.0s
5.0s
△
F2.04
Dropping Time of Swing
frequency
0.0～6000.0s
5.0s
△
F2.05
Set length
0m～65535m
1000m
×
F2.06
Number of pulses per
meter
0.1～6553.5
100.0
×
F2.07
Command when the length
attained
0: Not stop
0
×
1: Stop
F2.08
Set count value
1～65535
1000
×
F2.09
Designated count value
1～65535
1000
×
F2.10
Wakeup frequency
Dormant frequency (F2.12)～Fmax
0.00Hz
△
F2.11
Wakeup delay time
0.0～6000.0s
0.0s
△
F2.12
Dormant frequency
0.00～Wakeup frequency
0.00Hz
△
F2.13
Dormant delay time
0.0～6000.0s
0.0s
△
F2.14
Wake up mode selection
0: Frequency
0
×
1: Pressure
F2.15
Dormancy mode selection
0: Frequency
0
×
1: Pressure
F2.16
Voltage feedback source
Unit’s place: pressure feedback
0: AI1
1: AI2
2: DI7/HI pulse input
3: AI3 (VSX Only)
0
×
Ten’s place: pressure dormancy
mode
0:Positive direction, dormancy on
big pressure and wakeup on small
pressure
1:Negative direction, dormancy
on small pressure and wakeup on
big pressure
F2.17
Wake up pressure
0.0%～Dormancy pressure
10.0%
△
F2.18
Dormancy pressure
Wake up pressure～100.0%
50.0%
△
Group F3 Timing and Comparator
F3.00
Digital comparator source
1
Consistent with C1.00
0
×
F3.01
Digital comparator source
2
Consistent with C1.00
0
×
F3.02
Analog comparator source
1
0:No
1:Ai1
2:AI2
0
×
