Emotron VS Series Quick Start Guide
- 74 -
3:AI3 (VSX Only)
4:VP (When using LED keypad)
5:HI input
6:Setting frequency
(Max frequency :100.0%)
7:Output frequency
(Max frequency: 100.0%)
8:Output current
(Rated current 100.0%)
9:Bus voltage
10:Speed
(Motor rated speed: 100.0%)
F3.03
Analog comparator 1
higher value
0.0%～100.0%
80.0%
△
F3.04
Analog comparator 1 lower
value
0.0%～100.0%
20.0%
△
F3.05
Analog comparator source
2
0:No
1:Ai1
2:AI2
3:AI3 (VSX Only)
4:VP (When using LED keypad)
5:HI input
6:Setting frequency (Max
frequency :100.0%)
7:Output frequency(Max frequency:
100.0%)
8:Output current(Rated current
100.0%)
9: Bus voltage
10:Speed (Motor rated speed:
100.0%)
0
×
F3.06
Analog comparator 2
higher value
0.0%～100.0%
80.0%
△
F3.07
Analog comparator 2 lower
value
0.0%～100.0%
20.0%
△
F3.08
Timer 1 trigger source
Consistent with C1.00
0
×
F3.09
Timer 1 mode
0:Invalid
1:Delay mode
2:Alternating high and low electrical
level
0
×
F3.10
Timer 1 delay time
0s～60000s
10s
△
F3.11
Timer 1 high electrical level
time
0s～60000s
10s
△
F3.12
Timer 1 low electrical level
time
0s～60000s
10s
△
F3.13
Timer 2 trigger source
Consistent with C1.00
0
×
F3.14
Timer 2 mode
0:Invalid
1:Delay mode
2:Alternating high and low electrical
level
0
×
F3.15
Timer 2 delay time
0s～60000s
10s
△
F3.16
Timer 2 high electrical level
time
0s～60000s
10s
△
