Emotron VS Series Quick Start Guide
- 77 -
time
F3.63
Timer 12 trigger source
Consistent with C1.00
0
×
F3.64
Timer 12 mode
0:Invalid
1:Delay mode
2:Alternating high and low electrical
level
0
×
F3.65
Timer 12 delay time
0s～60000s
10s
△
F3.66
Timer 12 high electrical
level time
0s～60000s
10s
△
F3.67
Timer 12 low electrical
level time
0s～60000s
10s
△
Group H0: Communication Parameters
H0.00
Baud rate
0: 4800bps
1
×
1: 9600bps
2: 19200bps
3: 38400bps
4: 57600bps
5: 115200bps
H0.01
Data format
No check, data format
(1-8-N-2) for RTU
0
×
1: Even parity check, data format
(1-8-E-1) for RTU
2: Odd Parity check, data format
(1-8-O-1) for RTU
3: No check, data format
(1-8-N-1) for RTU
H0.02
Local address
1～247 0: Broadcast address
1
×
H0.03
Communication timeout
0.0～60.0s
0.0s
×
H0.04
Response time delay
0～200ms
1ms
×
H0.05
Master-slave
Communication Mode
0:The inverter is the slave
0
×
1:The inverter is the master
H0.06
The Master
Communication
Sending Data
0: Set frequency
0
×
1: Current running frequency
H0.07
Message return when
communication error
0: No return
1
1: Return
H0.08
U group return value
0: Positive and negative
0
△
1: Absolute value
Group L0 Keys and Display of Keypad Parameters
L0.00
MF.K key setting
0: No function
0
×
1: Jog
2: Forward/reverse switchover
3: local/ Remote selection
4: Jog reverse
L0.01
Keyboard operation display
Unit’s digit: Function selection of
STOP/RESET key
0: stop function of STOP/RESET
key is valid only in keyboard
operation mode
1: Stop function of STOP/RES
key is valid in any operation mode
001
×
